Used cNC turning and milling centers for sale (625)

Condition: excellent (used), Year of construction: 2014, CNC Turning and Milling Center Okuma Multus U4000 1SC 1500 BigBore Control: OSP-P 300S Year of manufacture: 2014 X-axis: 695 mm Y-axis travel: +150/-150 = 300 mm Z-axis: 1,600 mm B-axis: 240°, positioning in 0.001° increments C-axis: 360°, positioning in 0.001° increments Gsdpfx Aeyk Ddgsdbsip Turning diameter: 650 mm Turning length: 1,500 mm Spindle interface: Capto C6 Total tool stations: 80 Equipment: - NC tailstock - Travelling hydraulic steady rest AX 5 on NC axis - Coolant system with band filter - Kitagawa BB 212-11 hydraulic 3-jaw chuck - Automatic tool touch setter - High-pressure coolant system (IKZ) - Software option High Cut Pro (High-accuracy package with Super Nurbs) - CAS collision avoidance system - Main spindle orientation, electric - Multitool with turning function for Y-axis - Helix function - Automatic main power shut-off - DNC-DT interface - Machining Navi M-i (milling), speed control to minimize vibration - One-Touch IGF - Chip conveyor

Condition: good (used), Year of construction: 2004, functionality: fully functional, Gildemeister GMX 400 Year of manufacture: 2004 Control system: Siemens 840 D Powerline Max. turning diameter: 640 mm Turning length: 1,585 mm Standard turning diameter: 400 mm Control: Sinumerik 840D powerline Siemens Distance between centers: 1,930 mm Main spindle: Type: ISM 90 Max. speed: 4,000 rpm Drive power - main spindle: 36 / 45 kW Max. torque: 600 Nm Spindle diameter front bearing: 150 mm Spindle bore: 107 mm Max. bar diameter: 102 mm C-axis: 0.001° Chuck diameter: 315 (max. 400) mm Milling spindle: Max. speed: 12,000 rpm Drive power - milling spindle: 13.2 / 22 kW Max. torque: 100 Nm Tool holder: HSK-A63 Holding torque: 500 Nm y-axis: +/- 110 mm b-axis: +/- 120° Giedpoytpfzofx Adbjp c-axis: 1° x-travel: 550 mm Bearing diameter: 80 / 55 mm Tool magazine: Number of tool slots: 120 positions Tool holder: HSK-A63 Max. tool length: 350 mm Chip conveyor Feeds: Rapid traverse X1/Z1: 40/60 m/min Total power requirement: 70 kVA Machine weight approx.: 20.0 t

Condition: used, Year of construction: 1998, turning diameter 850 mm turning length 2000 mm turning diameter over slide rest 690 mm control Siemens type 840 C Cooling through the spindle 23 bar centre height 450 mm spindle diameter in front bearing 200 mm spindle hollow 128 mm power capacity 60 kW turning speeds 7-1800 U/min Torque 7908 Nm workpiece weight 4000 kg tailstock quill diameter 160 mm tailstock quill taper MT 5 3 jaw chuck Forckrath 600 mm Tool changer 60 Gsdpfxoyqv Anj Adboip work piece power 30 kW turning speeds 56-3000 U/min weight of the machine ca. 18 t dimensions of the machine ca. 6,3x2,4x3,3 m The machine has been completely overhauled. Capto C6 milling chuck Double prism lathe chuck The machine has many optional accessories that can be purchased separately. The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team

Condition: used, Year of construction: 1998, turning diameter 200 mm turning length 400 mm control Siemens type C 200-4 840 C spindle passage 65 mm Tool changer 2 x14 Pos. live tooling 2x Revoler weight of the machine ca. 4 t Main and counter spindle 3-jaw chuck with numerous jaws Hainbuch collets Many tool holders Various driven tools Bar loader "Index MBL" Chip conveyor with coolant unit Giodpfx Adoyqvygjbjp Complete set of spindle reducers etc. see photo The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team

Condition: used, Year of construction: 1997, turning diameter 400 mm turning length 1250 mm control Siemens type 840 C swing diameter 590 mm turning speeds 3500 U/min Torque 275/178 Nm spindle passage 50/65 mm clamping chuck diameter 250 mm output 43/28 kw Tool changer 80 Pos. tool taper Capto C 4 Counter spindle 3500 rpm Flexible head 1500/6000 rpm (2 gear ratios) Head with 4 stations (2 fixed stations for turning/2 milling stations) Power 9.4 kW Travel 1250 mm Spindle head ISO 702/1 size 8 (HSP) size 6 (GSP) Gisdpfx Adjyqvwfsbop The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team

Condition: used, Year of construction: 2007, turning diameter 325 mm turning length 600 mm control Siemens type 840D turning speeds 5000 U/min power capacity 25 kW total power requirement 35 kW weight of the machine ca. 6,5 t dimensions of the machine ca. 3,5x2,5x2,1 m Tool speed: 4500 rpm X-axis rapid traverse: 60 m/min Z-axis rapid traverse: 45 m/min Machine with Siemens 840 D powerline with Shopturn - C and Y axes, driven tools - IRCO ILS-RBK bar loader - Coolant system with internal coolant supply - Paper belt filter - Partial hollow clamping device - Oil mist separator - Counter spindle - Parts catcher The tech. Data are manufacturer or operator information and therefore non- Gisdpfx Adsyquwkebsp binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team

Condition: used, Year of construction: 1990, turning diameter 626 mm turning length 3000 mm control Siemens type 840D spindle passage 100 mm turning speeds 2800 U/min weight of the machine ca. 18 t Machine overhauled in 2003 and equipped with a Siemens 840 D - NC steady rest - 400 mm power chuck The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. Gsdpfxjyqtzzj Adbsip About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team

Condition: new, Year of construction: 2023, functionality: fully functional, HYUNDAI-WIA SE2200LY WITH FANUC 0i-T PLUS CONTROL CNC LATHE WITH Y AXIS. TURRET UPGRADE - 12 STATION 24 POSITION BMT45, LIVE TOOLS 6K RPM, 2.75 KW MACHINE CONSTRUCTION & FEATURES ▪ 8” STANDARD CHUCK SIZE. ▪ 30° SLANT BED ONE PIECE HEAVY DUTY CAST IRON CONSTRUCTION FOR HIGH ACCURACY & RIGIDITY. ▪ HIGH PERFORMANCE ROLLER LM GUIDEWAYS. ▪ 12 STATION HIGH SPEED RIGID SERVO DRIVEN TOOL TURRET - BMT45. [24 POSITION OPTION] ▪ 4,500 RPM HIGH POWER MAIN SPINDLE. ▪ 30 X 36 M/MIN RAPID TRAVERSE RATES – X & Z AXES. ▪ C-AXIS SPINDLE & WEDGE TYPE Y-AXIS. Swing Over the Bed Ø 600 MM Swing Over the Carriage Ø 600 MM Maximum Turning Diameter Ø 300 MM Maximum Turning Length 508 MM Bar Capacity – Main Spindle Ø 65 MM MAIN SPINDLE Chuck Size Ø 8” - 203 MM Spindle Bore Ø 75 MM Spindle Speed 4,500 RPM Motor (Max / Cont.) 15.0 / 11.0 KW Torque (Max / Cont.) 167 [150.3] NM Spindle Type BELT Spindle Nose A2-6 FEEDS Travel X 210 MM Travel Y 110 (± 55) MM Travel Z 560 MM Rapid Speed X 30 M / MIN Rapid Speed Y 10 M / MIN Rapid Speed Z 36 M / MIN Slide Type ROLLER LM GUIDEWAYS TURRET Number of Tools 12 [24 POSITION INDEX] Tool Size - OD 20 MM² Tool Size - ID Ø 32 MM Indexing Time 0.15 SEC / STEP Y-Axis Type WEDGE TYPE Milling Tool Speed 6,000 RPM Motor (Max / Cont.) 2.75 / 1.85 [2.8 / 3.8] KW Torque (Max / Cont.) 26.2 [27.0] NM Collet Size ER 20 - Ø 13 Type BMT45 HYDRAULIC NC TAIL STOCK (STD. LIVE CENTER) Taper MT#4 Quill Diameter Ø 56 MM Travel 580 MM Coolant Tank 200 L POWER SUPPLY Electric Power Supply 18 KVA Thickness of Power Cable OVER 16 MM² Voltage 415V / 50HZ / 3PH Floor Space (L x W) 2,960 X 1,730 MM Height 1,920 MM Weight 4,200 KGS STANDARD FACTORY FITTED MACHINE OPTIONS Giedex Tqkmepfx Adbep SPINDLE POSITIONING MAIN - 0.001 DEG INDEX (C1-AXIS) CHUCK CLAMP FOOT SWITCH MAIN SPINDLE 8 INCH 3-JAW HYDRAULIC CHUCK STD INC SET SOFT JAWS - MAIN SPINDLE CHUCK OPEN / CLOSE CONFIRMATION DEVICE MAIN SPINDLE STANDARD HYDRAULIC CHUCKING CYLINDER - HOLLOW 15" MONITOR FOR FANUC FOR STANDARD CNC SPECIFICATION - SEE MANUFACTURER'S BROCHURE HW ENERGY SAVING SYSTEM (HW-ESS) MACHINE GUIDANCE (HW-MCG) MANUAL VIEWER OPERATION MEMO PART PROGRAM STORAGE - 2MB (1,000 REGISTERABLE PROGRAMS) PREMIUM TOOL OPERATION SCHEDULING SMART GUIDE-I (CONVERSATIONAL PROGRAMMING) STANDARD COOLANT SYSTEM (NOZZLE) STANDARD COOLANT SYSTEM 0.5 BAR STANDARD COOLANT TANK 200 LITRES FULL SPLASH GUARDING SYSTEM STANDARD HYDRAULIC UNIT 35 BAR (15 LITRES) CALL LIGHT (1 COLOUR) BACK SPIN TORQUE LIMITER FRONT DOOR INTERLOCK TOOLBOX MAIN SPINDLE - 4,500 RPM, 15.0 / 11.0 KW, 167 NM BELT DRIVEN STANDARD TOOLING PACKAGE - SEE MANUFACTURER'S BROCHURE HYDRAULIC TYPE NC TAILSTOCK - MT#4 56 MM QUILL, STD LIVE CENTER 12 STATION BMT45 TURRET, LIVE TOOLS 6K RPM, 2.75 KW, 26 NM INCLUDED FACTORY FITTED MACHINE OPTIONS CHIP - BUCKET STANDARD CONVEYOR SIDE HINGED HIGH PRESSURE COOLANT SYSTEM 20 BAR IN LIEU OF STD CALL LAMP (3 COLOUR) - IN LIEU OF STD BARFEED INTERFACE - MAIN SPINDLE PARTS CATCHER - MAIN SPINDLE TRANSFORMER - 415V 3PH 50HZ QUICK TOOL SETTER - AUTO QUILL FORWARD / REVERSE CONFIRMATION DEVICE

Condition: excellent (used), Year of construction: 1996, functionality: fully functional, turning length: 1,000 mm, turning diameter: 350 mm, travel distance X-axis: 260 mm, travel distance Z-axis: 1,020 mm, CNC Lathe Manufacturer: Okuma Model: LB15 II-M 1SC-1000 Year of Manufacture: 1996 Control: OSP-7000L Country of Origin: Japan Delivery: Ex-stock Machine Features - Long turning length - Tailstock - Chip conveyor - Live tooling - One touch - IGF - Touch setter Technical Specifications - Working Areas - Swing diameter: 340 mm - Max. turning diameter: 350 mm (chuck work) - Max. turning length: 1000 mm Travel Distances - X-axis: 260 mm - Z-axis: 1020 mm Spindle - Speed: 45~4500 rpm - Standard spindle bore diameter: 62 mm - Spindle front bearing bore diameter: 100 mm - Chuck passage: 52 mm Turret - Number of stations: 12 - Tool holder: VDI40 Godoyrtkropfx Adboip - Indexing time station to station: 0.1 sec Feed Rates - Rapid traverse X/Z: 15,000/20,000 mm/min Tailstock - Quill diameter: 90 mm - Quill stroke: 120 mm Main Drive - Spindle motor: 15/11 kW Machine Dimensions: approx. 3315 x 1895 mm Machine Height: approx. 1905 mm Weight: approx. 5700 kg Optional - Transport organization and handling - Machine installation and setup - Commissioning of the machine

Condition: used, Year of construction: 2018, controller manufacturer: Fanuc, controller model: 31i-B5, _____ Description: Year of manuf. : 2018 Control : Fanuc 31i-B5 Turning diam. : 500 mm Turning length : 1280 mm Mainspindle: Technology:Motorspindle Speed:3.000 rpm Power (max.):38 kW Torque (max.):1.014 Nm Clamping cylinder:Hollow clamping cylinder Bar capacity:94 mm Workpiececlampig:3-Jawchuck, SMW Autoblok 250BB Subspindle: Technology:Motorspindle Speed:4.000 rpm Power (max.):40 kW Torque (max.):286 Nm Clamping cylinder:Partially hollow clamping cylinder Workpiececlamping:3-Jawchuck, SMW Autoblok HFK-N-210-52-3 Movement in W:1.130 mm Toolcarrier (X/Y/Z/B): Technology:Travelling column with millingspindle Speed:10.000 rpm Power (max.):20 kW Torque (max.):110 Nm Taper:HSK-A63 Swivelrange in B:+/- 105° In general: Toolmagazine:Chainmagazine, 40 Stations Giodpfsyul E Hsx Adbjp Movement in X/Y/Z:515/210/1.360 mm Rapid travers in X/Y/Z:18/18/30 m/min Equipment/Accessory: Positionsensor:Direct scales in all Axes Chipmanagement:Chip conveyor Coolantmanagement:Internal coolant unit with Paperbeltfilter and Highpressure, 70 bar Toolmeasurement:Automatic Measuringarm, Marposs TT30 :Rawmaterialfeeed. Interface Barloader prepared Finished part removal:Interface Partscatcher prepared Oilmistseparation:Interface mechanical prepared Toolholder:Misc. used Toolholder HSK-A63 Further Equipment:Rinsing pistol

Condition: used, Year of construction: 2013, controller manufacturer: Fanuc, controller model: 31i-B5, _____ Description: Year of manuf. : 2013 Control : Fanuc 31i-B5 Turning diam. : 500 mm Turning length : 1280 mm Mainspindle: Technology:Motorspindle Speed:3.000 rpm Power (max.):38 kW Torque (max.):1.014 Nm Clamping cylinder:Hollow clamping cylinder Bar capacity:94 mm Workpiececlampig:3-Jawchuck, SMW Autoblok 250BB Subspindle: Gjdpoyul Diofx Adboip Technology:Motorspindle Speed:4.000 rpm Power (max.):40 kW Torque (max.):286 Nm Clamping cylinder:Partially hollow clamping cylinder Workpiececlamping:3-Jawchuck, SMW Autoblok 210BB Movement in W:1.130 mm Toolcarrier (X/Y/Z/B): Technology:Travelling column with millingspindle Speed:10.000 rpm Power (max.):20 kW Torque (max.):110 Nm Taper:HSK-A63 Swivelrange in B:+/- 105° In general: Toolmagazine:Chainmagazine, 40 Stations Movement in X/Y/Z:515/210/1.360 mm Rapid travers in X/Y/Z:18/18/30 m/min Equipment/Accessory: Positionsensor:Direct scales in all Axes Chipmanagement:Chip conveyor Coolantmanagement:Internal coolant pump with Filter and High-pressure, 20 bar Toolmeasurement:Automatic Measuringarm, Marposs TT30 Rawmaterialfeeed:Barloader, Breuning Irco ILS-RBK 10016 Finished part removal:Interface Partscatcher prepared Oilmistseparation:Interface mechanical prepared Toolholder:Misc. used Toolholder HSK-A63 Further Equipment:Rinsing pistol

Condition: new, Year of construction: 2022, functionality: fully functional, HYUNDAI-WIA HD2200Y FANUC 0IT PLUS CNC LATHE WITH Y AXIS. MACHINE CONSTRUCTION & FEATURES ▪ ONE PIECE HEAVY DUTY CAST IRON BED CONSTRUCTION FOR HIGH ACCURACY & RIGIDITY. ▪ 4,000 RPM MAIN SPINDLE. ▪ 6,000 RPM LIVE TOOLING SPEED. ▪ HEAVY DUTY CUTTING WITH EXCELLENT PERFORMANCE. ▪ WEDGE TYPE Y-AXIS. ▪ 12 STATION HIGH SPEED RIGID SERVO TURRET - BMT55P ▪ HARDENED & GROUND BOX GUIDEWAYS Swing Over the Bed Ø 820 MM Swing Over the Carriage Ø 650 MM Maximum Turning Diameter Ø 300 MM Maximum Turning Length 610 MM Bar Capacity – Main Spindle Ø 65 MM MAIN SPINDLE Chuck Size Ø 8” - 203 MM Spindle Bore Ø 76 MM Spindle Speed (Rpm) 4,000 RPM Motor (Max / Cont.) 18.5 / 15.0 [22.5 / 15.0] KW Torque (Max / Cont.) 206.2 / 125.4 [215.0 / 143.3] NM Spindle Type BELT Spindle Nose A2-6 Travel X 215 MM Gijdjx Th Nyspfx Adbjp Travel Y 110 (± 55) MM Travel Z 680 MM Rapid Speed X 24 M / MIN Rapid Speed Y 10 M / MIN Rapid Speed Z 30 M / MIN HARDENED & GROUND BOX GUIDEWAYS Number of Tools 12 [24] Tool Size - OD 25 MM² Tool Size - ID Ø 20 MM Indexing Time 0.2 SEC / STEP Y-Axis Type WEDGE TYPE LIVE TOOL Motor (Max / Cont.) 5.5 / 3.7] KW Milling Tool Speed 6,000 RPM Torque (Max / Cont.) 52.5 / 26.5 NM Collet Size Ø 16 – ER25 Type BMT-55P TAILSTOCK Taper MT 4 Quill Diameter Ø 80 MM Quill Travel 120 MM Travel 680 MM TANK CAPACITY Coolant Tank 200 L Lubricating Tank 2.0 L Electric Power Supply 27 KVA Thickness of Power Cable OVER 25 MM² Voltage 415 V / 50 HZ / 3PH Floor Space (L x W) 3,380 x 1,800 MM Height 1,950 MM Weight 4,700 KGS INCLUDED FACTORY FITTED MACHINE OPTIONS CHIP - BUCKET STANDARD CHIP - CONVEYOR SIDE HINGED HIGH PRESSURE COOLANT SYSTEM 6.0 BAR IN LIEU OF STD CALL LAMP (3 COLOUR) - IN LIEU OF STD BARFEED INTERFACE - MAIN SPINDLE PARTS CATCHER - MAIN SPINDLE 30 KVA TRANSFORMER AND CABLE QUICK TOOL SETTER - AUTO PROGRAMMABLE TAILSTOCK IN LIEU OF STD TURRET UPGRADE - 12 STATION 24 POSITION BMT55P, LIVE TOOLS 6K RPM, 5.5 KW STANDARD FACTORY FITTED MACHINE OPTIONS SPINDLE POSITIONING MAIN - 0.001 DEG INDEX (C1-AXIS) CHUCK CLAMP FOOT SWITCH MAIN SPINDLE 8 INCH 3 JAW HYDRAULIC CHUCK STD INC SET SOFT JAWS - MAIN SPINDLE CHUCK OPEN / CLOSE CONFIRMATION DEVICE MAIN SPINDLE STANDARD HYDRAULIC CHUCKING CYLINDER - HOLLOW 15" MONITOR FOR FANUC HW ENERGY SAVING SYSTEM (HW-ESS) MACHINE GUIDANCE (HW-MCG) SMART GUIDE-I (CONVERSATIONAL PROGRAMMING) COOLANT TANK (SIDE TYPE) STANDARD COOLANT SYSTEM (NOZZLE) STANDARD COOLANT SYSTEM 0.5 BAR STANDARD HYDRAULIC UNIT 35 BAR (30 LITRES) CALL LIGHT (1 COLOUR) FRONT DOOR INTERLOCK TOOLBOX STANDARD TOOLING PACKAGE QUILL TYPE TAILSTOCK WITH STD LIVE CENTER

Condition: new, Year of construction: 2023, functionality: fully functional, HYUNDAI-WIA HD3100YA FANUC 0IT PLUS CNC LATHE WITH Y AXIS MACHINE CONSTRUCTION & FEATURES ▪ ONE PIECE HEAVY DUTY CAST IRON BED CONSTRUCTION FOR HIGH ACCURACY & RIGIDITY. ▪ 3,500 RPM MAIN SPINDLE. ▪ 5,000 RPM LIVE TOOLING SPEED. ▪ HEAVY DUTY CUTTING WITH EXCELLENT PERFORMANCE. ▪ WEDGE TYPE Y-AXIS. ▪ 12 STATION HIGH SPEED RIGID SERVO TURRET – BMT55P ▪ HARDENED & GROUND BOX GUIDE WAYS MACHINE CAPACITIES Swing Over the Bed Ø 800 MM Swing Over the Carriage Ø 670 MM Maximum Turning Diameter Ø 420 MM Giedpox Thu Njfx Adbsp Maximum Turning Length 760 MM Bar Capacity – Main Spindle Ø 81 MM MAIN SPINDLE Chuck Size Ø 10” - 254 MM Spindle Bore Ø 91 MM Spindle Speed (Rpm) 3,500 RPM Motor (Max / Cont.) 26.0 / 18.5 KW Torque (Max / Cont.) 734 / 522 NM Spindle Type BELT Spindle NoseA2-8 FEED Travel X265 MM Travel Y120 (± 60) MM Travel Z830 MM Rapid Speed X24 M / MIN Rapid Speed Y10 M / MIN Rapid Speed Z30 M / MIN Slide Type HARDENED & GROUND BOX GUIDEWAYS TURRET Number of Tools12 Tool Size - OD25 MM² Tool Size - IDØ 20 MM Indexing Time0.2 SEC / STEP Y-Axis Type WEDGE TYPE LIVE TOOL Motor (Max / Cont.) 5.5 / 3.7 KW Milling Tool Speed 5,000 RPM Torque (Max / Cont.) 70/0 / 35.4 NM Collet Size Ø 16 – ER25 Type BMT-65P TAIL STOCK Taper MT 5 Quill Diameter Ø 100 MM Quill Travelb120 MM Travel b830 MM Voltage 415 V / 50 HZ / 3PH Floor Space (L x W) 3,630 X 1,910 MM Height 1,960 MM Weight 6,200 KGS INCLUDED FACTORY FITTED MACHINE OPTIONS CONVEYOR & CHIP BOX HELICAL INTERPOLATION FUNCTION HIGH PRESSURE COOLANT SYSTEM 20 BAR IN LIEU OF STD CALL LAMP (3 COLOUR) - IN LIEU OF STD BARFEED INTERFACE - MAIN SPINDLE PARTS CATCHER - MAIN SPINDLE TRANSFORMER - 415V 3PH 50HZ QUICK TOOL SETTER - AUTO MAIN SPINDLE - 3,500 RPM, 26.0 / 18.5 KW, 734 NM BELT DRIVEN PROGRAMMABLE TAILSTOCK IN LIEU OF STD QUILL FORWARD / REVERSE CONFIRMATION DEVICE QUILL TYPE TAILSTOCK - MANUAL TYPE MT#5 100 MM DIA QUILL, 120 MM QUILL TRAV STANDARD FEATURES SPINDLE POSITIONING MAIN - 0.001 DEG INDEX (C1-AXIS) CHUCK CLAMP FOOT SWITCH MAIN SPINDLE 10 INCH 3 JAW HYDRAULIC CHUCK CHUCK OPEN / CLOSE CONFIRMATION DEVICE MAIN SPINDLE HYDRAULIC CHUCK PRESSURE INTERLOCK - MAIN SPINDLE STANDARD HYDRAULIC CHUCKING CYLINDER - HOLLOW 15" MONITOR HW ENERGY SAVING SYSTEM (HW-ESS) MACHINE GUIDANCE (HW-MCG) PART PROGRAM STORAGE - 2MB SMART GUIDE-I (CONVERSATIONAL PROGRAMMING) STANDARD COOLANT SYSTEM 0.5 BAR STANDARD COOLANT TANK 180 LITRES FULL SPLASH GUARDING SYSTEM CALL LIGHT TOOLBOX TOOLING PACKAGE QUILL TYPE TAILSTOCK 12 STATION BMT65P SERVO TURRET, LIVE TOOLS 5,000 RPM, 5.5 KW, 47.0 NM

Condition: used, Year of construction: 2018, machine/vehicle number: IntNr231502, CNC Short Turning Lathe – Citizen Miyano BNE-51MSY Year of manufacture: 2018 Condition: Very good, fully operational Availability: Available at short notice Description For sale is a Citizen Miyano BNE-51MSY CNC short-turning lathe in MSY configuration with main and sub spindle as well as Y-axis. Godpfxsyrx Rde Adbjip Equipment / Highlights • Main spindle + sub spindle • Y-axis • 2 tool turrets, each with 12 stations • Powered tools • Simultaneous machining possible • High rigidity and process reliability Technical data • Max. bar capacity: Ø 51 mm • Max. turning diameter: approx. 165 mm • Max. turning length: approx. 380 mm • Main spindle speed: up to approx. 5,000 rpm • Sub spindle speed: up to approx. 5,000 rpm • CNC control: Mitsubishi MELDAS • Machine weight: approx. 8,000 kg The machine is fully functional both electrically and mechanically. Complete technical documentation available. The machine can be inspected under power by appointment. Subject to prior sale, technical modifications, and errors!

Condition: used, Year of construction: 2023, machine/vehicle number: IntNr231501, CNC Lathe – DN Solutions (Doosan) LEO 1600 Year of manufacture: 2023 Equipment / Highlights - Horizontal CNC lathe - High-performance main spindle - Robust machine construction for precise dimensional accuracy - Tool turret with rapid indexing - Compact design, minimal footprint - User-friendly CNC control - High reliability and low maintenance requirements Technical Data - Max. turning diameter: approx. 300 mm Godsyrx Nmepfx Adbjip - Max. turning length: approx. 300 mm - Spindle bore: approx. Ø 52 mm - Main spindle speed: up to approx. 4,500 rpm - Tool turret: 12 stations - Control: FANUC CNC - Machine weight: approx. 2,200 kg The machine is fully operational, both electrically and mechanically. Comprehensive technical documentation available. The machine can be inspected under power by appointment. Subject to prior sale. Technical specifications and details are subject to change or error.

Condition: good (used), Year of construction: 2006, Year of manufacture: 2006 CNC control: Mitsubishi MSX-850 Giodpfx Ajv Egqzodbsp X-axis travel (mm): 260 Z-axis travel (mm): 795 Y-axis travel (mm): 100 Swing diameter over bed (mm): ø 920 Swing diameter over cross slide (mm): 742 Upper turret Number of tool stations: 12 Main spindle Max. spindle speed (rpm): 4,000 Spindle drive power (kW): 18.5/15 Spindle bore (mm): 91 Chuck type: Hollow Chuck (10") Manufacturer: KITAGAWA Tailstock Tailstock travel (mm): 734 Taper: MT3 Equipment Chip conveyor Signal light High-pressure pump Foot switch for chuck or collet system Interface for bar feeder Basic machine: Dimensions/Weight Length (mm): 2,620 Width (mm): 1,898 Height (mm): 2,200 Weight (kg): 6,140

Condition: good (used), Year of construction: 2004, turning length: 2,000 mm, Model: E-650H Control: Mazatrol 640M Pro Year: 2004 Giedpfx Adjxvyq Eobsp Distance Between Centres: 2000mm Swing Over Bed: 905mm Machine With: C Axis Y Axis Live Tooling/Milling B Axis 800mm Power Chuck Manual Steady 375mm Open Steady 600mm Air Filer Mist

Condition: used, Year of construction: 2003, Technical details: Gedpfex Dlhlsx Adbjip turning diameter: 270 mm turning length: 710 mm weight of the machine ca.: 6,5 t max. swing diameter: 590 mm with automatic loading and unloading system, chip conveyor G300 with "spindle bore clamping capacity 90mm" in tailstock version The machine has no driven tools. The information in the circuit diagram refers to the rotary drive for indexing the turret, not to driven tools. *

Condition: excellent (used), Year of construction: 2008, DOOSAN MX2000ST 9 AXIS MILL TURN CENTER Sub spindle and bottom Turret Both spindles have 200mm power chucks on at the moment but we also have a Heinbuck collet chuck available good package of tooling Shown working on our motorsport jobs all done in one! Godpjydigmsfx Adbjip Can be demonstrated if required.

Condition: like new (used), Year of construction: 2018, operating hours: 3,666 h, functionality: fully functional, turning length: 685 mm, turning diameter over cross slide: 650 mm, spindle speed (max.): 4,000 rpm, spindle bore: 91 mm, travel distance X-axis: 267 mm, travel distance Z-axis: 600 mm, rapid traverse X-axis: 30 m/min, rapid traverse Z-axis: 30 m/min, spindle nose: A2-8, overall weight: 5,400 kg, Equipment: documentation/manual, rotational speed infinitely variable, The machine is operational and set up in our showroom, and can be inspected by appointment! This DMG MORI CLX 450 V3 comes standard with: Gjdpfxoyh Inho Adbeip - 19" SlimLine PLC with TouchScreen. - Siemens electronic handwheel. - Chip conveyor. - High-pressure pump (12 bar). - Unused 3-jaw chuck (SMW AUTOBLOK KNCS-N-260-78 Ø260). - Various VDI-40 tool holders (static). - MARPOSS measuring arm incl. calibration holder (VDI-40). - Mechanical preparation for mist extraction unit. - Double foot pedal for clamping/unclamping main spindle. - Rinsing gun (5 bar) - Original DMG documentation. - Set of chemical anchors.

Condition: excellent (used), Year of construction: 2012, Maximum turning diameter 406mm, Maximum turning length 520mm, bar capacity 65mm, Y axis -/+ 51mm, Gsdpfxox T Dhls Adboip Spindle speed, 4,500 rpm, sub-spindle speed 4,500 rpm, milling speed 5,000rpm, 12 station turret, 18.5 kw main motor, C axis 0.001degrees, Fanuc I series control, parts catcher, tool setter, swarf conveyor, 3 jaw chucks to main and sub spindles, Iemca magazine barfeed

Condition: excellent (used), Year of construction: 2000, functionality: fully functional, turning length: 650 mm, turning diameter: 420 mm, travel distance X-axis: 300 mm, travel distance Z-axis: 675 mm, overall weight: 5,500 kg, Machine Equipment ▪ Interior suction system by Hengst Filtration (year of manufacture 2023) ▪ Touchsetter, tool measurement ▪ C-axis (main spindle) ▪ Tool breakage and wear monitoring ▪ 3-jaw chuck, Kitagawa B210, Ø250 mm ▪ Tailstock available ▪ Coolant supply, including through-tool supply ▪ Dialog programming IGF ▪ Chip conveyor (scraper type) Technical Details ▪ Max. turning length: 650 mm ▪ Max. turning diameter: 420 mm ▪ X-axis travel: 300 mm ▪ Z-axis travel: 675 mm ▪ C-axis travel: 360° ▪ Chuck passage: 72 mm ▪ Spindle bore: 95 mm ▪ Clamping cylinder bore: 95 mm ▪ Tool holder: VDI 40 ▪ Number of tool stations: 12 ▪ Spindle speed: 2,800 rpm ▪ Main spindle power: 22/30 kW ▪ M-spindle – driven stations: 12 ▪ M-spindle power: 5.5 kW ▪ M-spindle speed: 3,000 rpm ▪ Machine dimensions without accessories (LxW): approx. 2,700 x 1,900 mm Giodpfx Ajypkzisdbsp ▪ Machine height: approx. 1,885 mm ▪ Weight: approx. 5,500 kg Options ▪ Organization and execution of transport ▪ Machine delivery and installation ▪ Machine commissioning

Condition: excellent (used), Year of construction: 2021, Mazatrol SMOOTH control unit Max. Swing diameter: 695 mm Max. Machining diameter: 340 mm Gijdpsyp Iaisfx Adbop Max. Bar diameter: 35 mm Turning length: 600 mm Spindle speed 6,000 min-1 Counter spindle 12-position turret with driven tool Chip conveyor FMB bar feeder SL 80V

Condition: excellent (used), functionality: fully functional, Driven Tools Machine: MORI SEIKI SL2000 Turret Manufacturer: SAUTER ---- 2x→ No. 444-119 Turning Tool Holder 25 mm steel holder Fixed turning tool holder Price: on request 1x→ No. 444-201 Double Turning Tool Holder For main spindle and sub spindle With 1 clamping bar for 25 mm tool steels Fixed turning tool holder Price: on request 1x→ No. 444-210 Boring Bar Holder Cylindrical mount ø 32 mm second mount ø 32 mm; 57 mm to the rear Price: on request Godoynb E Njpfx Adbsip 1x→ No. 444-205 Turning Holder Mount 25 mm steel holder Price: on request

Condition: excellent (used), Year of construction: 2013, Doosan Puma MX2600ST Gsdsv Hyf Ujpfx Adbeip Fanuc 31i-A with Manual Guide i Swing over bed: Ø 1000 mm Max turning diameter: Ø 760 mm Max part length: 1540 mm Bar capacity: Ø 76 mm Movement: X1: 630mm Z1: 1585 mm Y: 230 mm (± 115 mm) X2: 220mm Z2: 1515 mm A: 1550 mm Left/right spindle: Spindle speed: 4000 rpm Spindle nose: A2-8 Spindle power: 22/26 kW C-axis: 360° (0.001) Milling spindle: 12,000 rpm Spindle power: 15/18.5/22 kW Spindle taper: Capto C6 B-axis: 0.001° Lower turret: 12 stations, 4000 rpm, BMT65P Tool magazine: 40 positions Automatic tool measurement Swarf conveyor Coolant for driven tools Coolant through milling spindle 1.5 KW , 2.0 MPA , 21.6 l/min Coolant pump for lower turret 2.2 KW , 1.0 MPA , 30 l/min Cutting force monitoring
